Grooved pulley
A single-groove pulley with a keyed bore and a pressed hub. The groove profile and the bore are turned in one setup.
How it is made.
The groove and the bore are turned in the same operation so they share an axis. The keyway is broached afterwards, and it is the feature that decides whether the pulley runs true or wobbles.
Illustrative specification
- Outside diameter
- Example · Ø104 mm
- Groove
- Example · 8 mm V, 38°
- Bore
- Example · Ø19 H7
- Keyway
- Example · 6 × 2.8 mm
- Material
- Example · cast iron
- Finish
- Example · oxide
Every value above is an illustrative example for a fictional range. It is not a quotation, a capability statement or a measurement of any real part.
What a long run changes.
The first piece and the four-hundredth are the same drawing. What differs is tool wear, and the dimension that moves first is usually the one nobody measures on every piece.
What it cannot confirm.
Whether the part survives its real use. That is established by testing under the real load, not by a first article on a bench.
