BODY / FRONT / FITTING
Low three-front sideboard
A long low cabinet appearance with three simple door faces and a raised plinth. Keep body, front, fitting and finish revisions together before a sample decision.
BI-221 / ORIGINAL FICTIONAL STUDY
DEMO SPECIFICATIONS / ACTUAL MATERIALS & SUITABILITY UNVERIFIED
- Example W × D × H
- 1800 × 450 × 700 mm — illustrative
- Body reference
- Low rectangular body / actual panels needed
- Front appearance
- Three flat door faces / actual movement unverified
- Surface record
- Walnut-like appearance / species and core unspecified
- Base question
- Raised plinth and actual body connection
- Fitting record
- Actual hinge, pull and fixing revisions required
- Study status
- Illustrative dimensions / original appearance concept
- Evidence scope
- Actual supplier drawings, physical sample and applicable records needed
No actual product, manufacturing drawing, certification or performance report is supplied.
STRUCTURE / MATERIAL / PHYSICAL SAMPLE
A useful sample
has clear questions.
Keep the actual product record and sample revision identifiable. Original images do not promise point-by-point agreement with illustrative specifications.
- 01
Separate the outside from each usable bay
Retain the real cabinet envelope and internal panel drawing. Door overlaps, panel thickness and hardware occupy part of the body. The nominal width and three-front appearance do not establish usable storage volume, interchangeable bays or shelf loading.
- 02
Retain the front-to-body junction
Request actual door substrate, edge, hinge, pull and body fixing references. Review movement and gaps using a physical junction sample. The rendered door lines do not establish soft-close performance, fitting compatibility or an assembly method.
- 03
Keep the finish identity with the full unit
A walnut-like appearance does not prove species, veneer, finish chemistry, emissions or sourcing. Retain a real material chip and a complete-unit reference as separate records. Load, stability and installation questions require actual product-specific evidence and responsible review.
Before the sample.
Download DEMO question notes →Question notes only. Not a cabinet shop drawing, cut list, hardware specification, anchoring instruction or load rating.
Are the fronts supplied with a verified soft-close fitting?
No fitting or movement performance is established. Request actual hardware and construction records.
Does the three-front map define usable storage?
No. Real body, panels, door movement and internal geometry are required.
Does a bay or front selection verify the cabinet installation?
No. Actual panel, backing, hardware, assembly and installation records are required. Request relevant product-specific load and stability evidence and responsible site review; the diagram supplies no anchoring solution.
